NICE3000
new
User Manual 8 Description of Function Codes
- 193 -
8
Value
Command
Source
Working Mode
Purpose Remarks
X Input Y Output
1
Distance
control
Detect
X input
signals
Output
Used during
normal
elevator
running
During inspection, the elevator runs at the
speed set in F3-11. During normal running,
the controller automatically calculates the
speed and running curve for the elevator
based on the distance between the current
oor and the target oor within the rated
elevator speed, implementing direct travel
ride.
8.1.3 Speed Setting
Function Code Parameter Name Setting Range Default Unit Property
F0-02
Running speed under operation panel
control
0.050 to F0-04 0.050 m/s
☆
F0-03
Maximum running speed 0.250 to F0-04 1.600 m/s
★
F0-04
Rated elevator speed 0.250–4.000 1.600 m/s
★
F3-10
Re-leveling speed 0.000–0.080 0.040 m/s
★
F3-11
Inspection speed 0.100–0.630 0.250 m/s
★
F3-21
Low-speed re-leveling speed 0.080 to F3-11 0.100 m/s
★
F6-48
Emergency evacuation switching
speed
0.010–0.630 0.010 m/s
★
F8-09
Emergency evacuation speed 0.000 to F3-11 0.050 m/s
★
●
F0-02 is used to set the running speed in the operation panel control mode.
Note that this function is enabled only when F0-01 is set to 0 (Operation panel control).
●
F0-03 is used to set the actual maximum running speed of the elevator. The value must be
smaller than the rated elevator speed (F0-04).
●
F0-04 is used to set the norminal rated speed of the elevator. The value of this parameter is
dependent on the elevator mechanism and traction motor.
●
F3-10 is used to set the elevator speed during re-leveling. This parameter is valid only when the
pre-open module (MCTC-SCB-A) is added to implement the re-leveling function (set in FE-32).
●
F3-11 is used to set the elevator speed during inspection and shaft auto-tuning.
●
F3-21 is used to set the elevator speed of returning to the leveling position at normal non-leveling
stop.
●
F6-48 is used to set the switching speed at shorting stator braking mode switched over to
controller drive via speed setting.
●
F8-09 is used to set the speed for emergency evacuation operation at power failure.
