NICE3000
new
User Manual 8 Description of Function Codes
- 199 -
8
If the motor has abnormal sound when the current is withdrawn at stop, increase the value of F2-
17 to eliminate the abnormal sound.
8.3.5 Other Vector Control Parameters
Function Code Parameter Name Setting Range Default Unit Property
F2-08
Torque upper limit 0.0–200.0 150.0 %
It is used to set the torque upper limit of the motor. The value 100% corresponds to the rated output torque
of the adaptable motor.
Function Code Parameter Name Setting Range Default Unit Property
F2-10
Elevator running direction 0–1 0 -
It is used to set the elevator running direction.
The values are as follows:
0: Direction unchanged
1: Direction reversed
You can modify this parameter to reverse the running direction (without changing the wiring of the motor).
When you perform inspection running for the rst time after motor auto-tuning is successful, check whether
the actual motor running direction is consistent with the inspection command direction. If not, change the
motor running direction by setting F2-10 to consistent with the inspection command direction.
Pay attention to the setting of this parameter when restoring the default setting.
8.4 Running Control Parameters
8.4.1 Running Speed Curve Setting
Function Code Parameter Name Setting Range Default Unit Property
F2-18
Startup acceleration time 0.000–1.500 0.000 s
F3-00
Startup speed 0.000–0.030 0.000 m/s
F3-01
Startup holding time 0.000–0.500 0.000 s
F3-02
Acceleration rate 0.200–1.500 0.600 m/s
2
F3-03
Acceleration start jerk time 0.300–4.000 2.500 s
F3-04
Acceleration end jerk time 0.300–4.000 2.500 s
F3-05
Deceleration rate 0.200–1.500 0.600 m/s
2
F3-06
Deceleration end jerk time 0.300–4.000 2.500 s
F3-07
Deceleration start jerk time 0.300–4.000 2.500 s
F3-09
Pre-deceleration distance 0–90.0 0.0 mm
