8 Description of Function Codes NICE3000
new
User Manual
- 214 -
8
F5-35 Terminal state display
1 2 3 4 5
A
Door 1 light
curtain
Door open button Door 1 open output
Door open button
display
System light curtain
state 1
B
Door 2 light
curtain
Door close button Door 1 close output
Door close button
display
System light curtain
state 2
C Door 1 open limit
Door open delay
button
Door lock signal
Door open delay
button display
Hall call elevator
lock input
D Door 2 open limit Direct travel ride signal Door 1 open output
Non-door zone
stop
Hall call re
emergency input
E Door 1 close limit Attendant signal Door 2close output Reserved Full-load signal
F Door 2 close limit
Direction change
signal
Door lock signal Buzzer output Overload signal
G Full-load signal
Independent running
signal
Up arrival gong Reserved -
DP Overload signal
Fireghter operation
signal
Down arrival gong
Energy saving
sign
-
8.8 Normal Running Function Parameters
8.8.1 Top/Bottom Floor Setting
Function Code Parameter Name Setting Range Default Unit Property
F6-00
Top oor of the elevator F6-01 to 40 9
-
F6-01
Bottom oor of the elevator 1 to F6-00 1
-
These two parameters are used to set the top oor and bottom oor of the elevator, determined by the
number of actually installed leveling plates.
8.8.2 Service Floor Setting
Function Code Parameter Name Setting Range Default Unit Property
F6-05
Service oors 1 (oors 1–16) 0–65535 65535
-
F6-06
Service oors 2 (oors 17–32) 0–65535 65535
-
F6-35
Service oors 3 (oors 33–40) 0–65535 65535
-
These parameters are used to set the service oors among oors 1–40. F6-05 (Service oors 1)
corresponds to oors 1–16. F6-06 (Service oors 2) corresponds to oors 17–32. F6-35 (Service oors 3)
corresponds to oors 33–40.
These parameters are set in the similar way.
The following part takes F6-05 as an example to describe how to set the service oors.
F6-05 is enabled through bit addressing.
The 16 bits of the function code respectively correspond to 16 oors. If a bit is set to 1, the elevator will
respond to calls of this oor; if this bit is set to 0, the elevator will not respond to calls of this oor.
