12-15
12.1.12 port-channel
Interface Config commands
Use this command to select the load-balance criteria of an aggregated port.
Syntax
port-channel (load-balance [src-dst-ip|src-dst-mac])
Parameters
Usage Guidelines
Use this command to configure and set the load balance to the aggregated port using (config-if)
static-channel-group
.
Example
The example below creates a channel group 1 with interface ge1 and ge 2.
RFS7000(config)#interface ge1
RFS7000(config-if)#static-channel-group 1
RFS7000(config)#interface ge2
RFS7000(config-if)#static-channel-group 1
The example below defines the load balance based on the IP or MAC address.
RFS7000(config)#interface sa1
RFS7000(config-if)#port-channel load-balance src--dst-ip
RFS7000(config-if)#
load-balance
[src-dst-ip|src-dst-mac]
Sets load-balancing for port channel.
• src-dst-ip – Source and Destination IP address based load balancing.
• src-dst-mac – Source and Destination MAC address based load balancing
