Spitfire – Maintenance Manual
124
AP-74096, Rev. 1.0, 09/06/05
Step 3 : Remove the wiper assembly
1 = Wiper assembly
Notes :
¾ Be careful removing the wiper assembly, so you don’t break the sensor located
close to the wiper.
No. Part
1 Sensor
Step 4 : Remove the wiperarm and reinstall the new one.
No. Part
1 Wiperarm assembly
2 T plate
To Next Page
