Spitfire – Maintenance Manual
64
AP-74096, Rev. 1.0, 09/06/05
3 = isolation tape
Step 14 : Reinstall all parts in the opposite order of the removal procedure.
Notes :
¾ During reinstallation of the plate, make sure there are no cables stuck.
4.3.1.4. Replacing the heater (Heater A) on a Spitfire
Before replacing the post fixer, make sure to have following items:
¾ 65” model : Heater A 64
¾ 90” model : Heater A 87
¾ 2 x press plate
¾ Silicone glue
To replace the heater on a Spitfire, please follow the instructions mentioned below.
Step 1 : Remove side cover L.
Step 2 : Remove side cover R.
Step 3 : Remove the front cover.
Step 4 : Remove the Y rail cover.
Step 5 : Remove the rear paper guide.
Step 6 : Remove the heater strip.
Step 7 : Degrease the plate.
Notes :
¾ Make sure the plate is cleaned properly. Dust, glue and other parts must be
removed.
