NEC T30A - Drive Settings; Table 4-17 Drive Settings Submenu; Table 4-18 Port Setting Submenu

-51-
4.4.2.3 Drive Settings
Table 4-17 Drive Settings Submenu
Submenu item
Default
Description
Port-A
-
Setting of Port A of the selected drive.
Port-B
-
Setting of Port B of the selected drive.
A set content is the same as PortA. The license is
necessary for the setting.
Media changer path
Drive #1
Enable
Drive #2-#4
Disable
Set the drive that controls the library.
Apply
-
The above-mentioned setting is applied.
Table 4-18 port setting submenu
Submenu item
Default
Description
Drive path
Port –A:Enbale
Setting of port-A(Enable / Disable)
Link Speed
(SAS model.)
3Gbps
Link Speed:
Specify the drive max Link Speed,
”3Gbps”, “6Gbps” are selectable.
Topology
(It is non-display in
the SAS model.)
Point to point
Specify the topology type
Set Loop ID
(It is non-display in
the SAS model.)
000
Specify the three-digit number Loop ID.
Valid number range is 000-125.
Link Speed
(FC model.)
8Gbps
Link Speed: Specify the drive Link Speed, ”Auto”,
“1Gbps”, “2Gbps”, “4Gbps” or “8Gbps” are
selectable.
