Neopost MACH 6 User Manual

SECTION 5
DISASSEMBLY AND ASSEMBLY
87
Replace Feeder Sensor
1. Remove Non-Operator Side Cover.
2. Disconnect the Feeder Sensor wire harness from the (J13)
Interface PCB terminal [A]. Cut wire ties as necessary.
3. Remove (2) screws [B] securing the Sensor Housing to the
Sensor Bracket.
4. Pull the Sensor Housing and Feeder Sensor away from the
Bracket. Remove (2) screws [C] securing Feeder Sensor to the
Sensor Housing.
5. Remove (2) screws [D] securing the Media Sensor to the Sensor
Bracket. This allows clearance to carefully pull the Sensor wire
through the slot in the Clamshell and Sensor Bracket.
6. Install in reverse order. IMPORTANT: Sensor must be
adjusted. See “Adjust the Feeder Sensor” below.
Adjust Feeder Sensor
1. Use a small flat tip screwdriver to adjust the Sensor. Access the
Sensor adjuster through hole [A] in the Sensor Housing.
2.
