SECTION 1
INTRODUCTION
7
Attach Media Side Guides and Rear Media Support Guide/Sled
1. Attach Media Side
Guide - Outer with two
screws [1] (included).
2. Attach Media Side
Guide - Inner with two
screws [2] (included).
3. Attach Rear Media Support Guide/Sled using
two screws (included) to secure it to the
mounting holes on Center Plate [3].
Attach Adjusting Knob [4].
NOTE: Two outside holes fit over socket
head screws.
