Install Print Platen & Drip Tray Assembly
Select appropriate Platen and Install it into Drip Tray:
Low Platen [1] (3 dots) is for media such as: heavy paper,
envelopes, card stock, cardboard, chip-board, padded
envelopes??
High Platen [2] (4 dots) is for thin, flexible media, such as:
sheet paper up to and including 32 lb??
Make sure Platen is positioned onto both Alignment Pins [A], in Drip Tray, as shown below.
CAUTION
It is very important that you get Platen positioned onto both Alignment Pins [A] or damage to
the system may occur when you close Clamshell and or start using printer.
