14-4
14.3.2 Connection of concentrates when acid port unit (option) is used
ＷＡＲＮＩＮＧ
z When acid rinse port unit (option) is used, aspiration ports of disinfectant and acetic acid
concentrates can be used as connectors of concentrates to be used. Check conformance
of connector types to rinsing mode to be executed.
14.3.2.1 Connection at water rinse
(1) Connection of any concentrate is not required. Connect all concentrate connectors to
respective rinse ports or engage them with respective connector receivers.
(2) Check correct connector connection.
14.3.2.2 Connection at disinfection/rinse
(1) Connect disinfectant concentrate connector placed at rear side of the machine to
disinfectant concentrate container.
(2) Connect other connectors to respective rinse ports or engage them with respective
connector receivers.
(3) Check correct connector connection.
14.3.2.3 Connection at acid rinse
(1) Connect acetic acid concentrate connector placed at rear side of the machine to acetic
acid concentrate container.
(2) Connect other connectors to respective rinse ports or engage them with respective
connector receivers.
(3) Check correct connector connection.
14.3.2.4 Connection at auto rinse 1 or 2
(1) Connect disinfectant concentrate connector placed at rear side of the machine to
disinfectant concentrate container.
(2) Connect acetic acid concentrate connector placed at rear side of the machine to acetic
acid concentrate container.
(3) Connect other connectors to respective rinse ports or engage them with respective
connector receivers.
(4) Check correct connector connection.
