Nipro SURDIAL - Environment

21-2
Protective class
and type
Class 1, type B No
21.1.4. Environment
Specifications Condition
Supply water
pressure
0.045 to0.74Mpa (0.5 to 7.5kgf/cm
2
)
(normal pressure）
No
Supply water flow
rate
≧750mL/min
At QD = 500mL/min
Supply water
Temperature
17～30℃
(5-30℃ if heat exchanger is used)
The temperature should be lower
than set dialysate temp. by ≧5℃.
The temperature fluctuation should
be within ±1℃/min.
At QD = 500mL/min
Drain
Capacity：≧1500mL/min
Height ：0 to 60cm above floor
No
Spaces
Spaces from circumference of
machine should be:
Top ≧5cm
Sides ≧10cm
Rear ≧20cm
Ventilation port of diameter of ≧
20cm should be provided.
Any of top, sides and rear should
be exposed to atmosphere.
No
Ambient temperature
15～35℃
(The temperature should be lower
than set dialysate temp. by ≧5℃.)
No
Ambient humidity
35-80％ (no dew condensation)
No
Temperature during
Storage or transport
If fluid is in fluid lines ： 5 to 50℃
If no fluid is in fluid lines: -10 to
50℃
No
Humidity during
Storage or transport
15～85％ (no dew condensation)
No
Atmospheric
Pressure
795 to 1062hPa at use, storage and
transport
No
Water quality
Quality meeting American National
Standard for Haemodialysis System
RD 5, 1981, Section 3.2 approved by
AAMI
No
Supply pressure
range of dialysate
Concentrate
MIN：Head below rinse port inlet by
136cm (-100mmHg)
MAX：Head above rinse port inlet by
No
