Nipro SURDIAL - Start of Rinsing (Example: RINSE4(AUTO2 C&D); Completion of Rinsing

14-5
14.4 Start of rinsing (example: RINSE4(AUTO2 C&D)）
(5) Check rinsing pattern.
(6) Check concentrate connection.
(7) Press [RINSE] SW.
z[RINSE] SW lamp is ON.
zRinsing is started.
zRinsing progress is displayed in screen.
［ＲＩＮＳＥ４］ ２１：００ ＜ Ｒｉｎｓｅ ＞
ＷＴＲ００→ＣＨＭ１５→ＤＷＬ３０→ＰＲＥ３０
ＰＲＥＲＩＮＳＥ ＳＴＡＲＴ ＴＯＭＯＲＲＯＷ １０：００
ＤＩＳＰ．
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
ＮＯＴＥ
z When rinsing pattern to execute disinfection/rinsing and acid rinsing in sequence is set
after selecting RINSE3 or RINSE4 mode, execution of the pattern is disabled even by
pressing [RINSE] SW.
z When rinsing pattern not to execute water rinse or prerinse next to other rinsing
operation is set after selecting RINSE3 or RINSE4 mode, execution of the pattern is
disabled even by pressing [RINSE] SW.
14.5 Completion of rinsing
(1) Check completion of all rinsing steps.
［ＲＩＮＳＥ４］ １０：４０ ＜ Ｅｎｄ ＞
ＷＴＲ００→ＣＨＭ００→ＤＷＬ００→ＰＲＥ００
ＰＲＥＲＩＮＳＥ ＳＴＡＲＴ ＴＯＤＡＹ １０：００
ＤＩＳＰ．
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
(2) Connect all concentrate connectors to respective rinse ports or engage them with
respective connector receivers.
(3) Check correct connector connection.
(4) Press [DIALYSIS] SW.
z[RINSE] SW is OFF.
z[DIALYSIS] SW lamp is ON.
zDialysis screen is displayed.
［ＤＩＡＬＹＳＩＳ］
ＶＰ： ０ｍｍＨｇ ＤＰ： ５ｍｍＨｇ ＣＯＮＤ： ０．０ｍＳ／ｃｍ
ＡＰ： ０ｍｍＨｇ ＴＭＰ： －５ｍｍＨｇ ＴＥＭＰ：２０．０゜Ｃ
Ｓ．Ｎ． ＳＱＨＤ ＰＲＩＭ ＴＥＳＴ ＤＩＳＰ．
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
