9-15
9.4.3 Test mode
Simple self diagnosis parameters and results are displayed.
Press [F･4] SW to release from test mode.
Press [F･5] SW to display settingⅠscreen.
［ＴＥＳＴ］
ＢＰ：ＯＫ ＣＬＶ：ＯＫ ＢＤ： ＶＰａ： ＶＰｂ：
ＶＰ： ＡＰ：
ＥＸＩＴ ＤＩＳＰ．
Fig. 9-19 Test mode screen
INDICATION DESCRIPTION
BP Display of BP test result by OK or NG
CLV Display of clamp test result by OK or NG
BD Display of bubble sensor test result by OK or NG
VPa Display of viscous pump a test result by OK or NG
VPb Display of viscous pump b test result by OK or NG
VP Display of venous pressure sensor test result by OK
or NG
AP Display of arterial pressure sensor test result by OK or
NG when required option is set
ＮＯＴＥ
z The self diagnosis is simple. Accordingly, all required checks can not be performed.
z The diagnosis is performed under specified conditions. If the conditions are not satisfied,
NG may be resulted.
