Nipro SURDIAL - Method to Set Dilution Rate of Acetic Acid Concentrate; Check of Residual Acetic Acid

11-5
11.4.3 Method to set dilution rate of acetic acid concentrate
It is necessary to release protect for setting based on the procedure specified in “Service
Manual” to set dilution rate of acetic acid concentrate.
(1) Press [F･5] SW to display maintenance menu screen.
(2) Press [F･3] or [F･4] SW to display "MODE7" and press [F･1] SW.
［ＭＡＩＮＴＥ ＭＥＮＵ（４／５）］
ＭＯＤＥ７：ＳＹＳＴＥＭ
ＭＯＤＥ８：ＳＥＲＶＩＣＥ ＦＲＥＱＵＥＮＣＹ
ＭＯＤＥ７ ＭＯＤＥ８ Ｐ．ＵＰ Ｐ．ＤＯＷＮ ＤＩＳＰ．
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
(3) Press [F･3] or [F･4] SW to blink "5.ACID RATIO".
(4) Press [F･1] or [F･2] SW to set dilution rate of acetic acid concentrate.
［ＭＡＩＮＴＥ ７］
５．ＡＣＩＤ ＲＡＴＩＯ ： １／３０
６．ＨＯＴ ＤＩＳＩＮＦＥＣＴＩＯＮ ＲＡＴＩＯ ： １／２６
＋ － ＵＰ ＤＯＷＮ ＭＥＮＵ
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
(5) Press [F･5] SW to return to maintenance menu screen.
11.4.4 Check of residual acetic acid
 ＷＡＲＮＩＮＧ
z If acetic acid remains in the machine even though the amount is small, patient life may be
threatened.
z Execute water rinse for 30 minute or more after acid rinse. The time, however, is changed
according to diluted acetic acid concentration and dialysate flow rate. It is recommended
to check residual acetic acid amount using test paper or reagent.
