16.3.4. Setting of syringe pump
16.3.4.1. Setting of cross-section ratio of syringe
Calculate ratio of cross-sectional area of syringe intended to be used to that of Nipro 20ml
syringe (292.5mm
2
) as 100% and set the ratio.
When the set ratio is 50%, pusher moves at a doubled speed compared with the case that
the ratio is 100% with exception that the speed is defined in the case of bolus infusion.
When the set ratio is 200%, it moves at a half speed compared with the case that the ratio is
100% with the exception.
(1) Press [F･5] SW to display maintenance mode 7 screen.
(2) Press [F･3] or [F･4] SW to indicate "20.MAINTENANCE MODE FREE".
［ＭＡＩＮＴＥ ７］
２０．ＭＡＩＮＴＥＮＡＮＣＥ ＭＯＤＥ ＦＲＥＥ ： ＯＦＦ
ＵＰ ＤＯＷＮ ＭＥＮＵ
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
(3) Press [F･1] SW to set to "ON".
［ＭＡＩＮＴＥ ７］
２０．ＭＡＩＮＴＥＮＡＮＣＥ ＭＯＤＥ ＦＲＥＥ ： ＯＮ
＋ － ＵＰ ＤＯＷＮ ＭＥＮＵ
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
(4) Instruction appears in [F･1] or [F･2] SW (＋/－). Check that setting is enabled by
blinking of items to be set.
(5) Press [F･3] or [F･4] SW to blink "1.SYRINGE RATE".
(6) Press [F･1] or [F･2] SW to change set value.
［ＭＡＩＮＴＥ ７］
１．ＳＹＲＩＮＧＥ ＲＡＴＥ ： １００
２．ＢＰ ＳＴＯＰ ＡＦＴＥＲ ＰＯＷＥＲ ＦＡＩＬ ： ＯＦＦ
＋ － ＵＰ ＤＯＷＮ ＭＥＮＵ
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
(7) Press [F･3] or [F･4] SW to indicate "20.MAINTENANCE MODE FREE".
(8) Press [F･1] SW to set to "OFF".
