9.3.4 Rinse end
During rinse end process, rinse result is displayed. Displayed information is defined by
selected mode.
ＮＯＴＥ
z If any SW on operation panel is not pressed for ≧30 minutes during rinse end screen is
displayed, back light is automatically turned off. By pressing the SW, the light is ON.
9.3.4.1 RINSE1: WATER
Rinse time of 00 min is displayed to indicate fluid line function stop.
Press [F･5] SW to display settingⅠscreen.
［ＲＩＮＳＥ１］ ２０：４５ ＜ Ｅｎｄ ＞
ＷＡＴＥＲ ＲＩＮＳＥ ００ｍｉｎ
ＤＩＳＰ．
Fig. 9-13 Rinse end screen when RINSE1 is selected
9.3.4.2 RINSE2:CHEMICAL
Rinse time of 00 min is displayed to indicate fluid line function stop.
［ＲＩＮＳＥ２］ ２０：４５ ＜ Ｅｎｄ ＞
ＣＨＥＭＩＣＡＬ ＲＩＮＳＥ ００ｍｉｎ
ＤＩＳＰ．
Fig. 9-14 Rinse end screen when RINSE2 is selected
9.3.4.3 RINSE3:AUTO1 C&D
Rinse time of 00 min is displayed to indicate fluid line function stop.
［ＲＩＮＳＥ３］ １０：４０ ＜ Ｅｎｄ ＞
ＷＴＲ００→ＣＨＭ００→ＤＷＬ００→ＰＲＥ００
ＰＲＥＲＩＮＳＥ ＳＴＡＲＴ ＴＯＤＡＹ １０：００
ＤＩＳＰ．
Fig. 9-15 Rinse end screen when RINSE3 is selecetd
9.3.4.4 RINSE4:AUTO2 C&D
Rinse time of 00 min is displayed to indicate fluid line function stop.
［ＲＩＮＳＥ４］ １０：４０ ＜ Ｅｎｄ ＞
ＷＴＲ００→ＣＨＭ００→ＤＷＬ００→ＰＲＥ００
ＰＲＥＲＩＮＳＥ ＳＴＡＲＴ ＴＯＤＡＹ １０：００
ＤＩＳＰ．
Fig. 9-16 Rinse end screen when RINSE4 is selected
