9-10
9.3.3 Rinse execution
During rinse progress, rinse step at that time is displayed. Displayed information is defined
by selected rinse mode.
ＮＯＴＥ
z If any SW on operation panel is not pressed for ≧30 minutes during prerinse wait
process, back light is automatically turned off. By pressing the SW or by starting prerinse,
the light is ON.
9.3.3.1 RINSE1: WATER
By rinse advancement, indicated rinse time is reduced to show left rinse time.
Press [F･5] SW to display settingⅠscreen.
［ＲＩＮＳＥ１］ ２０：３０ ＜ Ｒｉｎｓｅ ＞
ＷＡＴＥＲ ＲＩＮＳＥ １５ｍｉｎ
ＤＩＳＰ．
Fig. 9-9 Rinse execution screen when RINSE1 is selected
9.3.3.2 RINSE2: CHEMICAL
By rinse advancement, indicated rinse time is reduced to show left rinse time.
［ＲＩＮＳＥ２］ ２０：３０ ＜ Ｒｉｎｓｅ ＞
ＣＨＥＭＩＣＡＬ ＲＩＮＳＥ １５ｍｉｎ
ＤＩＳＰ．
Fig. 9-10 Rinse execution screen when RINSE2 is selected
9.3.3.3 RINSE3: AUTO1 C&D
Currently executed rinse step is double blinked. By rinse advancement, indicated rinse time
is reduced to show left rinse time.
［ＲＩＮＳＥ３］ ２１：００ ＜ Ｒｉｎｓｅ ＞
ＷＴＲ００→ＣＨＭ１５→ＤＷＬ３０→ＰＲＥ３０
ＰＲＥＲＩＮＳＥ ＳＴＡＲＴ ＴＯＭＯＲＲＯＷ １０：００
ＤＩＳＰ．
Fig. 9-11 Rinse execution screen when RINSE3 is selected
9.3.3.4 RINSE4: AUTO2 C&D
Currently executed rinse step is double blinked. By rinse advancement, indicated rinse time
is reduced to show left rinse time.
［ＲＩＮＳＥ４］ ２１：００ ＜ Ｒｉｎｓｅ ＞
ＷＴＲ００→ＣＨＭ１５→ＤＷＬ３０→ＰＲＥ３０
ＰＲＥＲＩＮＳＥ ＳＴＡＲＴ ＴＯＭＯＲＲＯＷ １０：００
ＤＩＳＰ．
