9-17
9.6 SettingⅡ screen
Part of required settings is displayed.
Press [F･3] or [F･4] SW to shift blink to desired position and press [F･1]or [F･2] SW to
change setting.
The setting change is enabled at any time required.
Press [F･5] SW to display maintenance mode menu.
［ＳＥＴＴＩＮＧ２］
１．ＢＣ（Ｗ＋Ａ＋Ｂ） ：１４０ ２．ＢＣ（Ｗ＋Ａ） ：１１０
３．ＡＣ（Ｗ＋ＡＣ） ：１４０ ４．ＭＯＤＥ ：ＢＣ１
＋ － ＜ ＞ ＤＩＳＰ．
Fig. 9-21 SettingⅡscreen
INDICATION DESCRIPTION
1.BC(W+A+B) Setting of final bicarbonate dialysate at mmol/l unit
2.BC(W+A) Setting of [water + A concentrate] concentration in
bicarbonate dialysate at mmol/l unit
3.AC(W+AC) Setting of final acetate dialysate concentration at
mmol/l unit
4.MODE Selection of dialysis mode corresponding to actually
used concentrate. Information related to the
concentrate is shown in maintenance mode 5 screen.
BC1: Bicarbonate dialysis
BC2: Bicarbonate dialysis
AC: Acetate dialysis
ＮＯＴＥ
z Settings not found in this screen are shown in settingⅡscreen and maintenance mode 2,
5, 6 and 7 screens.
