Chapter 12
PROCESS FLOW
12.1 Process flow
Rinsing operation is classified into 3 processes: “rinse wait”, “rinse” and “rinse end”.
Dialysis operation is classified into 5 processes: “dialysis wait”, “preparation”, “preparation
end”, “dialysis” and “recovery”.
Additionally, “air purge” process to be executed at the machine installation is found in
maintenance mode 9.
The process flow is as follows:
洗
12-1
浄待機工程
[DIALYSIS]SW_ON
洗浄工程
洗浄終了工程
透析待機工程
準備工程
準備完了工程
透析工程
回収工程
[DIALYSIS]SW_OFF
[RINSE]SW_ON[PRIP.]SW_ON
自動
[UF DIALYSE]SW_ON
洗浄終了
[PREP.]SW_ON [UF DIALYSE]SW_ON
[FUNCTION]SW_ON
Dialysis wait
Rinse wait
エア抜き工程
Air
p
ur
g
e
Pre
p
aration Rinse
Preparation
end
Rinse end
Dialysis
R y ecover
Fig. 12-1 Process flow
