Nipro SURDIAL - Settingⅰ Screen

9-16
9.5 SettingⅠ screen
Part of required settings is displayed.
Press [F･3] or [F･4] SW to shift blink to desired position and press [F･1]or [F･2] SW to
change setting.
The setting change is enabled at any time required.
Press [F･5] SW to display settingⅡscreen.
［ＳＥＴＴＩＮＧ１］
１．ＴＥＭＰ （°Ｃ）：３７．０ ２．ＢＡＲ ＧＲＡＰＨ ：ＤＰ
３．Ｓ．ＳＴＰ（ｍｉｎ）： ０ ４．ＢＯＬＵＳ （ｍｌ）：０．０
＋ － ＜ ＞ ＤＩＳＰ．
Fig. 9-20 SettingⅠ screen
INDICATION DESCRIPTION
1.TEMP Setting of dialysate temperature
2.BAR Changeover of DP and AP in DP/AP indicator
DP: Dialysate pressure AP: Arterial pressure
Blinking only when AP option is set
3.S.STP Setting of syringe stop time (from infusion end to UF
end)
Displayed only when required option is set.
4.BOLUS Setting of one shot infusion volume
Infusate of the set volume is infused automatically by
pressing FAST SW of syringe pump.
Displayed only when required option is set.
ＮＯＴＥ
z Settings not found in this screen are shown in settingⅡscreen and maintenance mode 2,
5, 6 and 7 screens.
