16.11.3. Setting of upper and lower dialysate pressure alarm limits
If arterial pressure alarm unit (option) is not used, the following steps from (1) to (4) are not
required.
The limits are set automatically sometime after pressing [UF DIALYZE] SW. When the limits
are set manually, follow the below procedures:
(1) Press [F･5] SW to display settingⅠscreen.
(2) Press [F･3] or [F･4] SW to blink "2.BAR GRAPH".
(3) Press [F･1] or [F･2] SW to set "DP".
(4) Check correct setting.
［ＳＥＴＴＩＮＧ１］
１．ＴＥＭＰ （°Ｃ）：３７．０ ２．ＢＡＲ ＧＲＡＰＨ ：ＤＰ
３．Ｓ．ＳＴＰ（ｍｉｎ）： ０ ４．ＢＯＬＵＳ （ｍｌ）：０．０
＋ － ＜ ＞ ＤＩＳＰ．
Ｆ・１ Ｆ・２
Ｆ・３
Ｆ・４ Ｆ・５
zDP ：Dialysate pressure indication in DP/AP indicator with DP indicating lamp ON
zAP ：Arterial pressure indication in DP/AP indicator with AP indicating lamp ON
(5) Check that DP indicating lamp is ON.
(6) Set the upper limit by operating [＜] or [＞] SW for the upper DP/AP limit setting.
(7) Set the lower limit by operating [＜] or [＞] SW for the lower DP/AP limit setting.
(8) Check correct setting.
(9) Press [F･5] SW to display dialysis screen.
