Nipro SURDIAL - Dialysis Screen; Dialysis

9-13
9.4 Dialysis screen
9.4.1 Dialysis
Part of dialysis related information is displayed during dialysis wait, preparation, preparation
end, dialysis and recovery processes.
Press [F･1] SW to select single needle dialysis mode.
Press [F･2] SW to select sequential HD mode.
Press [F･3] SW to select priming mode.
Press [F･4] SW to select test mode.
Press [F･5] SW to display settingⅠscreen.
［ＤＩＡＬＹＳＩＳ］
ＶＰ： １４０ｍｍＨｇ ＤＰ： １００ｍｍＨｇ ＣＯＮＤ：１４．０ｍＳ／ｃｍ
ＡＰ：－１００ｍｍＨｇ ＴＭＰ： ４０ｍｍＨｇ ＴＥＭＰ：３７．０゜Ｃ
Ｓ．Ｎ． ＳＱＨＤ ＰＲＩＭ ＴＥＳＴ ＤＩＳＰ．
Fig. 9-17 Dialysis screen
INDICATION DESCRIPTION
VP Current venous pressure
AP Current arterial pressure
Displayed only when required option is used
DP Current dialysate pressure
TMP Current TMP
COND Current conductivity
TEMP Current dialysate temperature
ＮＯＴＥ
z Select this screen during dialysis.
z Also refer to information found on operation panel.
z Information not found in this screen is shown in maintenance mode 1 screen.
