8.3.2 Components of blood line setting panel and their purposes and
functions
No. Component Purpose and function
1 Blood pump rotor Rollers used to deliver blood by squeezing blood line
tube
2 Blood pump cover Cover used to protect rotating mechanism of BP
BP operation stop is caused by opening cover.
3 Blood pump cover SW SW used to monitor opening of BP cover
4 Bubble detector Detector used to detect bubble in blood line
5 Clamp Clamp used to close blood line tube for blood flow stop
6 Tube holder Holder used to set blood line tube
7 Venous pressure inlet port
Port used to introduce venous pressure for its
measurement
8 Pusher Used to advance syringe plunger
Engageable with the plunger by receiving its flange in it
Release of lock by pushing in, enabling manual right or
left movement
9 Syringe holder Used to hold syringe
10 Syringe holding lever Used to hold syringe in syringe holder by rotation
Syringe holding by rotating it to cross syringe and
release of the holding by parallel placement of it with
syringe
