6-1
Chapter 6
INSTALLATION
Environmental condition and methods of unpacking, assembling, connection and wiring required to
install the machine and methods of disposal of used machine and packaging materials are specified
below. These operations should be performed by trained and qualified person(s) only.
6.1. Installation environment
The following requirements should be fulfilled to assure safe and effective use of the machine.
6.1.1. Ambient conditions
During :
Use Daily storage
Storage for one month
or more; and Transport
with contained fluid
Transport
without fluid
Temp. (°C)
15 to 35 10 to 40 5 to 50 -10 to 50
35 to 80 15 to 85 15 to 85 15 to 85
Relative humidity
(%)
No condensing
Atmospheric
pressure (hPa)
795 to
1062
795 to 1062 795 to 1062 700 to 1062
NOTE
Avoid direct exposure of the machine to sunlight
6.1.2. Power supply
6.1.2.1. When machine power rating is AC 230V
The machine is designed to be operated by power supply of AC 230V ± 10%, 50 Hz.
Receptacle conforming to protective earth type plug of AC rating of 230V, ≧ 10 A is required
to connect with the machine. Connect the plug with the receptacle correctly.
6.1.2.2. When machine power rating is AC 110V
The machine is designed to be operated by power supply of AC 110V ± 10%, 50 Hz.
Receptacle conforming to protective earth type plug of AC rating of 110V, ≧ 20 A is required
to connect with the machine. Connect the plug with the receptacle correctly.
