Chapter 20
MACHINE MOVING AND CAUTIONS
 ＷＡＲＮＩＮＧ
z DO NOT place the machine at 5°or more against vertical line under loading any object on
container support or hanger to prevent falling down of the machine.
z DO NOT load any object on container support or hanger during transport of the machine.
z DO NOT place the machine at 10°or more against vertical line under loading any object
on container support or hanger t even under no loading to prevent falling down of the
machine.
(1) Release two locks (front right and rear left sides) placed at casters.
(2) Move the machine under holding it upright.
(3) Move the machine by pushing rear side of it. It is recommended to push rear side by
one person and to support front side by other person to guide because forward view of
the former person may be blocked by the machine.
Moving
di ti
Fig. 20-1 Moving of machine
20-1
