ＮＯＴＥ
z DO NOT move the machine on floor with irregular surface.
z If floor is stepped by ≧3 cm or is provided with groove of a width of ≧3 cm, place flat
plate such as steel plate capable of supporting the machine weight on the step or groove.
z Move the machine under contact of the four casters with floor.
z To move the machine on slope, direct front side of it upward. Move the machine by at
least 2 persons.
Moving direction Moving direction
Fig. 20-2 Upward movement Fig. 20-3 Downward movement
z Move the machine with care whether there is no obstacle on the way.
z To transport the machine by truck, hold the machine upright. DO NOT lay down the
machine.
(４) Follow the below procedures to lift the machine, if required:
Lift the machine by 4 persons.
Each of 3 of them should hold each leg of the machine frame as shown in Fig. 20-2.
The remainder one person should support rear side of the machine to prevent
falling down of it as shown in Fig. 20-2.
ＣＡＵＴＩＯＮ
z DO NOT hold plastic cover. Hold frame.
20-2
