8-4
No. Component Purpose and function
18 Water supply port
Port used to connect hose for supplying purified water
to the machine
19 Drain port
Port used to connect hose for draining used dialysate
20 Port for connector of
disinfectant concentrate
connector
Port use to connect connector of disinfectant
concentrate container when disinfectant or acid rinsing
is not executed
21 Connector for disinfectant
concentrate container
Connector used to connect disinfectant concentrate
container during disinfection/rinsing; or that used to
connect
acetic acid concentrate container during acid rinsing
22 Blood leak sensor
Sensor used to detect blood leak
23 Priming flow rate regulating
needle valve
Valve used to regulate flow rate of priming solution
24 Tray
Tray used to hold tools during dialysis by placing it on
the machine top
