HOTSPOT GATEWAY
110 System Administration
2. System administrators can set the properties for each room from the subscriber
side of the HSG. The system automatically detects which port number the
administrator is using and allows them to enter the fields for the room
corresponding to the port they are using.
If required, click on the check box for
In Room Port Mapping to enable this
feature.
3. If you enabled In Room Port Mapping, you must assign a Username and
Password. You will need these when you perform port mapping from the
subscriber side of the HSG.
Go to “In Room Port Mapping” on page 113 to map rooms from the subscriber
side of the HSG.
4. Select No Port Location Mapping if you are not using Port-based access. ... or go
to Step 5:
5. Select 802.1Q one-way or 802.1Q two-way (VLAN IDs) if you are using a
device that understands VLAN IDs. These options tell the HSG that the device
can process VLAN IDs to identify which port-location the information is coming
from, and how to bill it... or go to Step 6 (next page):.
For security reasons, this feature should be disabled when in room
port mapping (from the subscriber side of the HSG) is completed.
When assigning port-locations, the “port” is the VLAN ID (when using
802.1Q one-way or 802.1Q two-way).
