HOTSPOT GATEWAY
Introduction 25
Product Specifications
Specifications
PERFORMANCE
User Support:
50 users concurrently, with option to expand (up to 150 users)
Throughput:
75Mbits/s*
*As defined by RFC1242, Section 3.17
PHYSICAL
Dimensions:
1U, free standing
8.66 (W) x 10.00 (D) x 1.75 (H) inches
220 (W) x 254 (D) x 44 (H) mm
Weight:
4.05 pounds (1.84 Kg)
O
PERATING ENVIRONMENT
Temperature: 5° – 40° C
Relative Humidity: 20% – 90%
P
OWER
44 watt AT power supply
C
OMPLIANCE
FCC Part 15, Subpart B, Class B
CE Mark
CENELEC EN 55022:1998 Class B
CENELEC EN 60950
CENELEC EN 61000-3-3:1995
CISPR 22: 1997 Class B
UL Std. 1950
CAN/CSA Std. C22.2 No. 950
I
NTERFACES
Subscriber / Network Interface:
3 10/100 Mbps Ethernet RJ45
Management Port :
1 DB9 serial
