Various settings
11
MP1020/1025/1035 11-31
11.3 Specifying the status settings for the functions (Soft-
ware SW)
By specifying the Software SW numeric values (mode, bit, HEX) according to
the usage conditions of this machine, the status of each function can be
changed.
2
Reminder
Do not change the modes or bits that are not mentioned in this manual.
Software SW
An example of the Bit Selection (binary numbers) and HEX Selection (hexa-
decimal numbers) displays are shown below.
Item Description
Mode Represents the setting with a three-digit number. Type in the
value using the keypad.
Bit An eight-digit number that configures the mode status. Specify
the status of the function by specifying the bit for each number
from 7 to 0 with a binary number (1 or 0).
HEX The status of each function is displayed by a combination of
hexadecimal numbers (0 to 9, A to F). When Bit Selection is
“00110000”, HEX Selection can be represented as “30”.
The status of the mode is specified in Bit Selection or HEX Se-
lection.
Decimal
number
Bit Selection (binary number) HEX Selection (hexadecimal
number)
0 0000 0000 00
1 0000 0001 01
2 0000 0010 02
3 0000 0011 03
4 0000 0100 04
5 0000 0101 05
6 0000 0110 06
7 0000 0111 07
8 0000 1000 08
9 0000 1001 09
10 0000 1010 0A
11 0000 1011 0B
12 0000 1100 0C
To Next Page
