Advanced operations

>>>WARNING SOUND

INK ERRORS

Press the OK button.

>>>>INK ERRORS

Press the Down button to select OFF.

>>>>INK ERRORS

OFF

Press the OK button.

>>>>INK ERRORS

OFF
