106
Maintenance
Congure nozzle map
When lines are missing on the nozzle print pattern or the ink is not ejected straight, that means that a nozzle is
clogged. Nozzle map can be congured to set a nozzle that will be used instead of the clogged nozzle. With this
function, good print quality can be maintained without reducing the print speed.
Up to 10 nozzles can be set with nozzle map for each print head.
Nozzle map can be congured manually or automatically.
* Only nozzles that are completely clogged are detected with automatic configuration. Nozzle map must be
congured manually in the following cases.
- The nozzle is partially clogged.
- The nozzle does not eject ink straight.
* Use media of more than 762 mm (30 inches) with automatic conguration.
Manual conguration
page 107
Automatic conguration
page 108
How to choose between manual and automatic conguration
Congure nozzle map manually in the following cases.
- The media used is less than 762 mm (30 inches).
- A nozzle is partially clogged.
- A nozzle does not eject ink straight.
- You want to set the nozzles more precisely.
- You want to quickly complete conguration.
- You are used to manual conguration.
Congure nozzle map automatically in the following cases.
- There are no partially clogged nozzles.
- All nozzles eject ink straight.
- You do not want to set the nozzles manually.
- You are not used to manual conguration.
