Oki IP-6620 - Print on a thick media

182
Advanced operations
Print on a thick media
Change the height of the print heads
Be sure to adjust the height of the print heads when printing on thick media to prevent the print heads from
contacting the media.
Change the print head height depending on the media used with the head up/down mechanism.
On the operation panel enter the print head height adjustment option in the preset menu.
1
PRINTER READY
01: PAPER / 1626mm
Press the MAINTENANCE button.
2
MAINTENANCE
2
START MAINTENANCE
Press the Down button to select PH
MAINTENANCE.
3
MAINTENANCE
2
PH MAINTENANCE
Press the OK button.
4
>PH MAINTENANCE
2
SHEET MOUNT CLNG
Press the Down button to select ADJUST PH
HEIGHT.
5
>PH MAINTENANCE
2
ADJUST PH HEIGHT
Press the OK button.
6
>>ADJUST PH HEIGHT
2
OK?
Press the OK button.
CARRIAGE IS MOVING
PLEASE WAIT
Carriage stops moving.
7
OPEN COVER
PH HEIGHT ADJ
Open the front cover and the maintenance
area cover and loosen the two head securing
screws.
