160

Advanced operations

>INK AMOUNT EXTENSION

AVAILABLE INK

Press the OK button.

X.XXL: Amount of ink that can be used

>>AVAILABLE INK

X.XXL

Press the OK button.

Export printer information

Menu information can be exported in the PDF format to the USB drive.

USB port

Insert a USB drive in the USB port.

The FAT32 format is recommended for the USB drive.

PRINTER READY

01: PAPER / 1626mm

Press the MAINTENANCE button.

MAINTENANCE

START MAINTENANCE

Press the Down button to select EXPORT

DATA TO USB.

MAINTENANCE

EXPORT DATA TO USB

Press the OK button.

>EXPORT DATA TO USB

USB DRIVE CONNECTED?

Press the OK button.

>EXPORT DATA TO USB

EXECUTING
