Advanced operations
Reset the media edge guards during printing
If the media edge guards are not correctly placed on the media edges, or if you want to adjust the edge guards’
position during printing, you can manipulate the seat part of the media edge guards to adjust them without
opening the front cover.
CAUTION
Do not make the adjustment when the carriage passes above the media edge guards.
If the media edge guards or the media touch the print heads surfaces, it may cause clogged nozzles or a malfunction.
Bend the media edge guards to slide them smoothly.
<To slide the media edge guards to the left>
Media edge guard moving direction
Pivot
Directions of strength (bend the guard in
the counter-clockwise direction)
<To slide the media edge guards to the right>
Media edge guard moving direction
Pivot
Directions of strength (bend the guard
in the clockwise direction)
