Loading the media
Procedure to remove the roll media (feed side)
1
Lift the pressure roller lever.
2
Rotate the ange to rewind the media.
3
Move both the right and left anges to
remove them from the tube, and then remove
the media.
Notes
If a lot of media remains and the roll is heavy, use tools
to help you and remove the media using the loading
procedure in the reverse order.
Be careful that the media does not fall when removing
the media holders from the roll. Workers may be injured
if their hands get caught under the media or if the media
falls on their feet.
