Before printing

Printer heater unit

The printer is equipped with three heaters for ink fusing and image quality stabilization.

• Print heater (front)

Penetrates ink into media to fuse the ink.

• Preheater (rear)

Preheats media.

• Afterheater (finishing)

Dries ink to stabilize print quality.

Media

* These three heaters are controlled independently.

The temperature of the heaters can be controlled from the operation panel, the RIP software and CP_

Manager.

WARNING



Do not touch these heaters to avoid burn as they become hot.

Before printing

Loading the media Adjustment Maintenance

Advanced

operations

Troubleshooting Menu tree Appendix
