Advanced operations

START DRAINING

BOTTLE IS EMPTY?

Conrm that the waste ink bottle is empty

and press the OK button.

Draining starts.

Y:YY : Required time (min:sec, decrease every 10 seconds)

DRAINING

REQUIRED TIME Y:YY

NO K CARTRIDGE

OPEN INK BOX COVER

Head wash (LCIS)

Refer to the leaet supplied with the cleaning liquid set.

Priming the ink system after head wash (CIS)

PRINTER READY

01: PAPER / 1626mm

Press the MAINTENANCE button.

MAINTENANCE

START MAINTENANCE

Press the Down button to select PH

MAINTENANCE.

MAINTENANCE

PH MAINTENANCE

Press the OK button.

>PH MAINTENANCE

SHEET MOUNT CLNG

Press the Down button to select PRIME INK

SYSTEM.
