Before printing
LCD messages
This LCD installed on the printer operation panel can display two rows of 20 characters.
Examples of messages displayed on the LCD are shown below.
Menu display
The level of the menu is indicated by the number of > marks displayed at the left of the upper row on the LCD.
Top menu:
Top menus are displayed when the MENU button, the ADJUST button or other menu buttons are pressed. No
>
marks are displayed for top menus.
<Display example>
MENU
2
INFORMATION
Level 1 to level 4 menus:
A
> mark is added each time a lower menu is selected starting from a top menu.
<Display examples>
>EDIT MEDIA PRESETS
2
SELECT PRESET NO.
(Level 1 menu)
>>>MEDIA EDGE GUARDS
2
ON
(Level 3 menu)
Menu and parameter selection display
A
2
mark is indicated at the left of the lower row on the LCD when menus or parameters can be selected in the
current menu using the Up and Down buttons.
<Display examples>
MAINTENANCE
2
START MAINTENANCE
(Menu selection)
>>>COLOR STRIPE
2
OFF
(Parameter selection)
OK button input display
A mark is indicated at the right of the lower row on the LCD when you can enter a menu or execute an operation
in the current menu by pressing the OK button.
<Display examples>
>EDIT MEDIA PRESETS
2
MISC SETTINGS
(Enter a level 2 menu)
NOZZLE PRINT
2
PRINT?
(Execute an operation)
