Manual legend (Notational rules)
The notational rules used for explanation in this guide are as follows:
Marks
WARNING
Boxes marked with a WARNING describe points of caution to avoid serious personal injury.
CAUTION
Boxes marked with a CAUTION describe points of caution to avoid injury to yourself or damage to the printer.
TIP:
This mark indicates useful information, additional items and important operations.
Reference mark
This mark is followed by a reference section or page number.
Capping unit side and maintenance area side
To identify the printer’s right and left, this guide mentions the capping unit side and maintenance area side as follows.
Viewed from the printer’s front (media take-up side)
Maintenance area side Capping unit side
Viewed from the printer’s rear (media supply side)
Maintenance area sideCapping unit side
A maintenance area is arranged. Capping unit is equipped.
