Oki ML1120 Technical Reference Guide

Technical Reference Guide – Specifications > 192
> Cut-sheet multipart forms
Paper width: 100 – 257 mm (3.9 – 10 in)
Paper length: 100 – 257 mm (3.9 – 10 in)
Weight: 11 - 15 lbs (40 - 58 gsm) standard
Number of copies: Original plus 4 copies
Thickness: 0.39 mm max. (0.015 in max.)
Binding: Line glued to the top of form.
> Continuous Paper
Tractor feed unit can handle sprocket paper a width of 76.2
to 254 mm (3 to 10 in).
Ream weight: 14 - 22 lbs (52 - 82 gsm)
Multipart paper: Max. 0.39 mm (0.015 in) total thickness.
Multiple-part paper should be held together by spot-
pasting or crimping on both sides and should be free of
wrinkles.
> Cut form envelope
Weight: 24 lbs max. (90 gsm max.)
Thickness:
0.39 mm max. (0.015 in max.)
6-1/2 x 3-5/8 in
8-7/8 x 3-7/8 in
9-1/2 x 4-1/8 in
> Continuous envelope
Weight: 24 lbs max. (90 gsm max.)
Thickness: 0.39 mm max. (0.015 in max.)
PAPER TYPE REAM WEIGHT NUMBER OF SHEETS
Carbon-lined
paper
11 - 15 lbs
(40 - 58 gsm)
5 sheet maximum including
original
Pressure
sensitive paper
11 - 15 lbs
(40 - 58 gsm)
5 sheet maximum including
original
Interleaf paper
(standard)
9 - 11 lbs
(34 - 45 gsm)
4 sheet maximum including
original
Interleaf paper
(carbon-lined)
9 lbs (34 gsm) 4 sheet maximum including
original

Oki ML1120 Specifications

General

Noise level	49.7 dB
Maximum duty cycle	18000 pages per month
Maximum number of copies	9 copies
Power requirements	120 - 220V
Dimensions (WxDxH)	889 x 587 x 379 mm

Weight and Dimensions

Dimensions (W x D x H) (imperial)	35 x 23.1 x 14.9 \
