Technical Reference Guide – Appendix D – Media specifications > 229
NOTE
Printing data in the light-grey filled areas is possible, but may
affect paper feed accuracy.
Print specifications do not apply to the last sheet of paper.
In setting print formats, take note that printing data beyond
printing areas may impair print quality or adversely affect the
printer.
Each horizontal perforation is to be accurately at the centre of
the space between paper feed holes. Placing horizontal
perforations close to paper feed holes causes the paper to
peel, and carriage snagging on the paper may occur.
Do not attempt to save paper by allowing the sprocket holes in
the last page to come off the pin tractor sprockets.
P
APER
QUALITY
The following paper quality is usable:
E Upper edge of printing area 19.05 mm (3/4 in)
F Upper edge of printable area 6.35 mm (1/4 in)
G Paper end detecting position Approx. 72 mm
(2.84 in)
H Left printing prohibition area 12.7 to 22.2 mm (1/2
to 7/8 in) for paper
widths between 3 and
11 in.
14.0 to 22.2 mm (0.55
to 7/8 in) for paper
width 12 in.
I Right printing prohibition area 11.43 mm (9/20 in)
[I': 12.7 mm (1/2 in)].
DIMENSION NAME SPECIFICATION
VALUE
TYPE PAPER QUALITY
Single-part Form White, high quality paper
Multipart Form Pressure-sensitive paper, carbon-backed paper or
interleaved paper ( Note 1)
