Oki ML1120 Technical Reference Guide

Technical Reference Guide – Interface specifications > 21
P ARALLEL INTERFACE CIRCUITS
P ARALLEL INTERFACE TIMING CHART
S UPPORT MODE
Compatible
Nibble (PnP Device ID only)
U NIVERSAL S ERIAL B US (USB)
Universal Serial Bus Specification Revision 2.0 full speed
compliance.
BUSY, ACKNOWLEDGE, PAPER END, SLECT, FAULT
LVC161284
1
2 HL
+5 V
240 Ω
(a) Receiver
(b) Driver
DATA BIT1 to
DATA BIT8
DATA
STROBE
(H)
(L)
(H)
(L)
(H)
(L)
ACKNLG
BUSY
μs
min
s
min
0.5 μs
min
μs
max
s
1.0
1.0
μ
0.5
T busy
t1 =1~4
μ
t1
t1

Oki ML1120 Specifications

General

Noise level	49.7 dB
Maximum duty cycle	18000 pages per month
Maximum number of copies	9 copies
Power requirements	120 - 220V
Dimensions (WxDxH)	889 x 587 x 379 mm

Weight and Dimensions

Dimensions (W x D x H) (imperial)	35 x 23.1 x 14.9 \
