Technical Reference Guide – Operator interface > 44
ML1190 eco
U
NRECOVERABLE
ALARMS
Unrecoverable alarms are shown below. The numbers of blinks of
the alarms indicate the states of the alarms.
Alarm indication consists of main blinking and sub-blinking. Main
blinking is the concurrent blinking of the SEL and ALARM LEDs
and sub-blinking is the blinking of only the SEL LED.
LED SEL
(GREEN)
ALARM
(RED)
STATUS
ALARM
Paper End O R
Paper Lever B R
Paper Jam (Load jam,
Ejection jam)
BR
Head Temperature B R R
NOTE
O: LED continuously ON
B: LED blinking (400 ms ON, 400 ms OFF)
R: Current LED indication retained
X: LED stays off
ALARM INDICATION ALARM CONTENTS
MAIN BLINKING SUB-BLINKING
1 1 Head homing alarm
2 Spacing alarm
2 1 Program ROM alarm
2 CG ROM alarm
To Next Page
