Technical Reference Guide – Appendix D – Media specifications > 224
Vertical dimension
The following is standard for the vertical dimension T.
For usable areas, see “Paper size and printing areas” on
page 228.
Horizontal dimension
The following is a standard for the horizontal dimension Y.
For usable areas, see “Paper size and printing areas” on
page 228.
Folding dimension
The following is a standard folding dimension. Paper is to be fan-
folded along perforations.
F
EED
HOLE
(
SPROCKET
HOLE
)
POSITIONS
AND
SIZES
Sprocket hole positions and sizes are shown below. For this
section, a centre line is defined as a centre-to-centre line
between any two sprocket holes approximately 254 mm apart in
the direction of paper feed.
TYPE (NAME) DIMENSION (MM) TOLERANCE (MM)
T11 279.4 ±0.5
TYPE (NAME) DIMENSION (MM) TOLERANCE (MM)
Y10 254.0 +1.5, -0.5
TYPE (NAME) DIMENSION
(MM)
CORRESPONDING VERTICAL
DIMENSION TYPE
F11 279.4 T11
ITEM DIMENSION (MM) REMARKS
Distance between
centre line and paper
edge on same side
A 6.35 ±0.7 6.35 mm is
standard.
