Technical Reference Guide – Operator interface > 74
I
NITIALISING
MENU
SETTINGS
To restore the menu settings to their initial values, carry out the
steps below.
1. Set the Power Switch to OFF.
Serial I/F
menu
Parity Set parity. None
Odd
Even
Ignore
Serial Data 7/
8 Bits
Set serial data
length.
8 bit
7 bit
Protocol Set protocols. DTR
X-ON/X-OFF
DTR & X-ON/X-OFF
Diagnostic
Test
Set/Cancel loop
testing of the
serial interface.
No
Yes
Baud Rate Set the
transmission
speed of the
serial interface.
9,600 bps
4,800 bps
2,400 bps
1,200 bps
600 bps
300 bps
19,200 bps
DTR Signal Set whether to
switch the DTR
signal of the
serial interface
by Select/
Deselect or hold
it after power-
on.
Ready on Power UP
Ready on Select
Busy Time Set the
minimum time it
takes to switch
from a busy
state to a ready
state.
0.2 sec
1.0 sec
MENU ITEM FUNCTION SETTING
NOTE
The values adjusted by the Adjustment menus are not
initialised by the following procedure.
To Next Page
