Technical Reference Guide – Operator interface > 77
S
ETTING
TOF
POSITION
AT
THE
PLACE
OF
USER
’
S
CHOICE
TOF position can be set at the place of user’s choice. The
reference position refers to the first line of the paper i.e. the
position to which the printer feeds the paper when automatically
loading paper.
1. Move paper Lever to the position of the paper to be set.
2. Continuous paper: Set the paper in Pin Tractor.
Single sheets: Do not insert the paper.
3. Continuous paper: Push the LOAD/EJECT button and the
paper will be fed into the printer.
Single sheets: Set the paper in the tray and the paper will
be fed to the printer.
4. Switch to off line.
5. Push the LOAD/EJECT button continuously and adjust the
position of printing, start by combining the following
buttons.
Forward (minute reline): LOAD/EJECT button + SEL button
Rear (minute reline): LOAD/EJECT button + LF/FF button
When the paper is positioned at the required TOF, release the
buttons in Step 5 above. To save this position as the TOF, press
and hold down the LOAD/EJECT and the LF/FF buttons together
for 3 seconds under the Select condition.
NOTE
Adjusting of TOF can be done in cut sheet mode or continuous
forms mode.
NOTE
The range set for TOF is between 2.12 mm (1/12 in) and 368/
4 mm (14.5 in). Outside the range, the paper cannot be
moved.
NOTE
Do not turn the platen knob or switch off the printer during
the above procedure.
