2KZ/2K0
1-3-84
U464
Setting: [Bias Target/Gamma Target]
1. Select the item to be set.
2. Change the setting value using the +/- or numeric keys.
3. Press the start key. The value is set.
Method: [Calib]
1. Select the item to be set
2. Press the start key. The operation starts.
To stop operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description Setting
range
Initial set-
ting
1st Setting of target (Yellow) 10 to 1000 935/400
2nd Setting of target (Cyan) 10 to 1000 895/200
3rd Setting of target (Magenta) 10 to 1000 885/200
4th Setting of target (Black) 10 to 1000 846/130
Display Description
Regist Executes the calibration to correct registration.
Gamma Executes the calibration to quantities of light.
Paper Int Executes the calibration between paper.
Color Regist Executes the calibration to color registration.
Service Manual Y113010-4
