2KZ/2K0
1-1-2
Continuous copying 1 to 999 sheets
Light source White LED
Scanning system Flat bed scanning by CCD image sensor
Photoconductor a-Si drum (diameter 30 mm)
Image write system Semiconductor laser:
Charging system Contact charger roller method
Developer system
Touch down developing system
Developer: 2-component
Toner replenishing: Automatic from the toner container
Transfer system
Primary: Transfer belt
Secondary: Transfer roller
Separation system Small diameter separation, separation electrode
Cleaning system Counter blade cleaning
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system
One axis IH established method
Heat source: IH inverter heating
Abnormally high temperature protection devices: thermostat
CPU PowerPC464 (800MHz)
Main
memory
Standard 1024 MB
Maximum 2048 MB
Interface
Standard
USB interface connector: 1 (USB Hi-speed)
USB host: 2 (USB Hi-speed)
Network interface: 1 (10BASE-T/100/1000BASE-TX)
Option
eKUIO slot: 2
Resolution 600 × 600 dpi
Operating
environment
Temperature 10 to 32.5 °C/50 to 90.5 °F
Humidity 15 to 80% RH
Altitude 2,500 m/8,202 ft or less
Brightness 1,500 lux or less
Dimensions (W × D × H) 590 × 590 × 748 mm / 23 1/4” × 23 1/4 “× 29 7/16”
Weight 80 kg / 176.4 lb (with toner containers)
Space required (W × D) 874× 590 mm / 34 7/16” × 23 1/4” (using MP tray)
Power source
120 V AC, 60 Hz, more than 12.0 A
220 - 240 V AC, 50/60 Hz, more than 6.5 A
Options
Paper feeder (single cassette), Paper feeder (double cassette), Document
finisher, Network kit, Fax kit, Expanded memory, Card Authentication KIT
Item
Specifications
20ppm 25ppm
Service Manual Y113010-4
